Note:. The remainder of this post below is still very important, but I’d like to make sure everyone has the most up-to-date information about compatibility between the different DLLs and parallel port cards out there. If you’re looking for my patched io.dll for Willem programmer compatibility, see below. Last year I bought a Willem EPROM programmer board from. It’s basically a cool little board with various sockets for plugging in EPROM/EEPROM/Flash/etc chips for reading/erasing/writing. Apparently it can even program some AVR microcontrollers. I have the PCB50 version of the board.

• Software Download

Here’s the deal. It has a USB port, but it’s only for supplying power.

(For AT89XXX programmer software) Download here: PICkit 2 V2.61: 2012.10. DOS version Willem programmer software. The number of chips supported is not updated. Willem EPROM Programmer. Download Program read file *.pdf. Software can run on New & Old(Original willem Eprom) schematic.

In order to provide the best platform for continued innovation, Jive no longer supports Internet Explorer 7. Attention, Internet Explorer User Announcement: Jive has discontinued support for Internet Explorer 7 and below. Jive will not function with this version of Internet Explorer. Please consider upgrading to a more recent version of Internet Explorer, or trying another browser such as Firefox, Safari, or Google Chrome. (Please remember to honor your company's IT policies before installing new software!) • • • •. Torrent karma motif software.

All communication goes through the parallel port. As everybody should know at this point, the parallel port is on the way out. No, scratch that. The parallel port is long gone. I had to use a really old HP Pavilion with a Celeron running Windows 98 to do anything with it. The programmer worked great, and I was able to fix a computer’s BIOS chip that I had messed up while trying to hack its BIOS. Let’s fast forward to over a year later (a.k.a.

I have a homebuilt PC with an Intel DX58SO motherboard and a Core i7 CPU, running Windows 7 Ultimate edition, 64-bit. The DX58SO literally has no legacy peripherals, other than a single PCI slot. It has no PS/2 ports, no parallel port, no serial ports, and no standard IDE ports. It does have a variety of types of PCI Express slots, though. I recently bought a sweet from Newegg. (Note: Newegg’s product specs lie about this card — the parallel port does not support EPP or ECP mode, according to a sticker on the box, even though Newegg says it does).

I remembered that I had my programmer and decided I totally needed to get it working in Windows 7. Easier said than done. It’s difficult enough to get low-level legacy stuff working in Windows 7, but when you’re using the 64-bit edition, a lot of older stuff breaks even more. Also let’s remember that add-on parallel ports do not get mapped to the standard I/O addresses for parallel ports (0x378 and 0x278), but instead some other random address (mine is at 0x3000). I tried running the software that came with the board, but it just gives me errors and actually won’t let me exit without forcing it to quit from the task manager. Removable disk repair software 4.0.1.6 crack. Let’s go on a Google adventure.

Software Download

Google lesson #1: sometimes when you’re looking for info about Windows 7 64-bit, you can find very useful stuff when you search for Vista 64-bit (or XP 64-bit) instead. My first search was willem vista 64-bit. The second result was a digg posting titled Willem Eprom for Vista and 64bit XP (digg post is no longer available; link removed). The linked page is a forum posting at a forum called onecamonly.com.

The post is by the admin of the site, and he mentions to install software called and then a modified io.dll file. The first comment on the digg posting was by a user named rabitguy, who said he had a Willem board working on Windows 7 64-bit with tvicport and iodllwrapper. So I kept seeing this io.dll and iodllwrapper stuff. What exactly is it? Let’s Google for “io.dll”. The first result is to a.

Basically, it explains that it’s a library allowing direct port access from several different Windows versions. Except it doesn’t mention Windows Vista or Windows 7, or anything 64-bit at all. Well, I looked in the installation directory for the Willem software that came with my Sivava programmer board, and sure enough, in C: Program Files (x86) EPROM50, there’s an evil file named io.dll. So that’s why it doesn’t work. So anyway, I searched for iodllwrapper, deciding to follow the advice of rabitguy.

The first result is to a. I did a search on that page for “Willem” and found a posting by Toni Wilen who wrote a 64-bit-compatible io.dll wrapper which depends on TVicPort and uploaded it as an attachment to the forum, called iodllwrapper.zip. He even included the source code. So I think I get it.

He wrote a DLL that provides all the functions that io.dll would provide, except rather than implementing the raw functionality himself, he forwards the relevant function calls to TVicPort, which handles all the low level stuff (in a manner that works on 64-bit operating systems!). Actually it’s a pretty genius idea. So I downloaded his DLL and tried it out, replacing the stock io.dll file that came with the Willem software with his new wrapper.
